Hwm .125 Aluminium Sheet
Peb .125 txhuas ntawv muaj lub zog tshwj xeeb thiab ua haujlwm ntev rau ntau yam kev siv. Tshawb xyuas peb qhov ntau thiab tsawg thiab specifications. Tau txais cov ntawv zoo aluminium los ntawm cov chaw tsim khoom txhim khu kev qha. Tiv tauj peb hnub no!
Xa kev nug
Product Details ofHwm .125 Aluminium Sheet
Zoo siab txais tos rau koj qhov Trusted qhov chaw, cov chaw tsim khoom thiab cov muag khoom ntawm hwm .125 txhuas ntawv. Peb tshwj xeeb hauv kev muab cov ntawv zoo txhuas txhuas uas muaj lub zog zoo dua, ua haujlwm ntev, thiab ntau yam rau ntau yam kev siv.
Nrog rau peb txoj kev mob siab rau kev ua tau zoo thiab cov neeg siv khoom txaus siab, peb yog koj tus neeg xa khoom mus rau txhua qhov koj xav tau .125 txhuas ntawv. Nyeem rau kom pom cov txiaj ntsig ntawm peb cov ntawv txhuas txhuas thiab tshawb xyuas peb cov khoom lag luam nthuav dav.
Cov txiaj ntsig ntawm .125 Cov Ntawv Txhuas Txhuas:
Lub zog thiab Durability:
Peb .125 txhuas ntawv yog engineered los muab tshwj xeeb lub zog thiab durability. Nrog lub thickness ntawm .125 ntiv tes (3.175 hli), cov nplooj ntawv no muab cov qauv tsim nyog rau kev tiv thaiv hnyav, cuam tshuam, thiab ntau yam ib puag ncig. Txawm hais tias siv hauv kev tsim kho, tsheb, lossis kev siv hauv kev lag luam, peb cov ntawv txhuas ua kom muaj kev ua haujlwm ntev.
Corrosion Resistance:
Aluminium yog ib txwm tiv taus corrosion, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau kev siv sab nraum zoov thiab dej hiav txwv. Peb cov ntawv .125 txhuas tau txais kev kho saum npoo thiab txheej txheej kom ntxiv dag zog rau lawv cov khoom tiv thaiv corrosion. Qhov no ua kom ntseeg tau tias koj cov haujlwm tseem muaj kev tiv thaiv thiab tswj hwm lawv qhov kev thov kom zoo nkauj txawm tias nyob hauv ib puag ncig nyuaj.
Lub teeb yuag thiab ntau yam:
Txawm hais tias lawv lub zog muaj zog, peb .125 aluminium ntawv yog lub teeb yuag, ua rau lawv yooj yim los tuav thiab nruab. Cov yam ntxwv no muaj txiaj ntsig tshwj xeeb hauv cov ntawv thov uas txo qhov hnyav yog qhov tseem ceeb, xws li aerospace, kev thauj mus los, thiab kev tsim vaj tsev. Tsis tas li ntawd, peb cov ntawv txhuas txhuas tuaj yeem tsim tau yooj yim, tso cai rau ntau yam kev tsim thiab tsim kom tau raws li koj cov kev xav tau tshwj xeeb.
Khoom Specifications:
Txhawm rau muab cov lus qhia dav dav ntawm peb cov ntawv .125 txhuas, thov mus saib cov lus hauv qab no uas qhia ntau yam tshwj xeeb:
Table 1: Standard Loj thiab Thicknesses
| Loj (dav x Length) | Thickness (.125 Aluminium Sheet) |
|---|---|
| 48" x 96" | .125 "(3.175 hli) |
| 48" x 120" | .125 "(3.175 hli) |
| 60" x 120" | .125 "(3.175 hli) |
| Custom Sizes | .125 "(3.175 hli) |
Table 2: Mechanical Propertie
| Khoom | 1050 | 1060 | 1100 | 3003 | 3004 | 5052 | 5083 | 5086 | 5754 |
|---|---|---|---|---|---|---|---|---|---|
| Tensile zog | 22,000 | 23,000 | 23,000 | 27,000 | 31,000 | 33,000 | 46,000 | 42,000 | 31,000 |
| (psi) | (152) | (159) | (159) | (186) | (214) | (228) | (317) | (290) | (214) |
| Yield zog | 16,000 | 15,000 | 14,000 | 21,000 | 23,000 | 28,000 | 33,000 | 32,000 | 24,000 |
| (psi) | (110) | (103) | (97) | (145) | (159) | (193) | (228) | (220) | (165) |
| Elongation | 30 feem pua | 28 feem pua | 35 feem pua | 20 feem pua | 12 feem pua | 12 feem pua | 16 feem pua | 12 feem pua |
Table 3: Chemical Composition (Example Values)
| Element | 1050 | 1060 | 1100 | 3003 | 3004 | 5052 | 5083 | 5086 | 5754 |
|---|---|---|---|---|---|---|---|---|---|
| Aluminium (Al) | 99.50% ua | 99.60% ua | 99. 00 feem pua | 98.60 :ua | 98. 00 feem pua | 95,70 :ua | 95.50% ib | 95.30% ib | 97,90 :ua |
| Copper (Cu) | 0.05 feem pua | 0.05 feem pua | 0.05 feem pua | 0.10 feem pua | 0.25 feem pua | 0.10 feem pua | 0.10 feem pua | 0.10 feem pua | 0.20 feem pua |
| Hlau (Fe) | 0.40 feem pua | 0.35 feem pua | 0.40 feem pua | 0.70 feem pua | 0.70 feem pua | 0.40 feem pua | 0.40 feem pua | 0.40 feem pua | 0.40 feem pua |
| Manganese (Mn) | 0.05 feem pua | 0.03 feem pua | --- | 1. 00 feem pua | 1. 00 feem pua | 0.10 feem pua | 1. 00 feem pua | 1. 00 feem pua | 0.50 feem pua |
| Magnesium (Mg) | --- | --- | --- | 1.20 feem pua | 1.30 feem pua | 2.50 feem pua | 4. 00 feem pua | 3.50 feem pua | 2.60 feem pua |
| Silicon (Si) | 0.25 feem pua | 0.25 feem pua | 0.95 feem pua | 0.60 feem pua | 0.30 feem pua | 0.25 feem pua | 0.40 feem pua | 0.40 feem pua | 0.40 feem pua |
| Zinc (Zn) | 0.07 feem pua | 0.03 feem pua | --- | --- | 0.25 feem pua | 0.10 feem pua | 0.25 feem pua | 0.25 feem pua | 0.20 feem pua |
| Lwm tus | 0.15 feem pua | 0.15 feem pua | 0.05 feem pua | 0.15 feem pua | 0.15 feem pua | 0.15 feem pua | 0.15 feem pua | 0.15 feem pua |
Qhov chaw thov:
Kev tsim kho kev lag luam:
Roofing thiab siding
Phab ntsa panels
Cov yam ntxwv ntawm cov khoom
Automotive Kev Lag Luam:
Lub cev panels
Trim thiab accents
Kev tiv thaiv hauv qab
Kev Siv Hluav Taws Xob:
Machinery thiab khoom siv
Manufacturing Cheebtsam
Lub tank cia
Aerospace thiab Marine Applications:
Kev tsim dav hlau thiab nkoj
Sab hauv vaj huam sib luag
Marine decking
Quality Assurance:
Ntawm Koj Qhov Chaw Tso Cai, peb muab qhov tseem ceeb tshaj plaws ntawm txhua kauj ruam ntawm kev tsim khoom. Our.125 aluminium ntawv yog tsim los ntawm kev siv thev naus laus zis thev naus laus zis thiab ua raws li cov qauv kev lag luam nruj. Peb ua nruj me ntsis kev ntsuam xyuas kom ntseeg tau tias peb cov khoom ua tau raws li cov neeg siv khoom xav tau. Los ntawm kev xaiv peb .125 txhuas ntawv, koj tuaj yeem muaj kev ntseeg siab rau kev ntseeg siab thiab kev ua tau zoo ntawm koj cov haujlwm.
Tiv tauj peb:
Yog xav paub ntxiv txog peb .125 txhuas ntawv los yog los tham txog koj cov kev xav tau tshwj xeeb, thov hu rau peb pab neeg paub. Peb nyob ntawm no los pab koj nrhiav kev daws teeb meem zoo tshaj plaws rau koj daim ntawv thov. Hu rau peb ntawm [Phone Number] lossis email rau peb ntawm [Email Chaw Nyob]. Koom tes nrog peb niaj hnub no thiab paub txog qhov sib txawv ntawm cov ntawv zoo aluminium.
