1050 Aluminium Disc Rau Teeb pom kev zoo Reflector
1. Taw qhia
1050 aluminium disc rau teeb pom kev zoo reflectoryog ib qho tshwj xeeb siab -purity aluminium khoom engineered kom tau raws li qhov xav tau kho qhov muag, thermal, thiab mechanical xav tau ntawm niaj hnub illumination systems.
Nrog cov ntsiab lus ntawm aluminiumNtau dua lossis sib npaug li 99.5%, no alloy muaj exceptional reflectivity (85-95%Tom qab daim iav polishing), superior thermal conductivity (227 W/m·K), thiab zoo heev formability (elongation30-40%nyob rau hauv O temper), ua rau nws nyiam substrate rau siab -kev ua tau zoo teeb pom kev zoo reflectors.
Cov khoom muaj peev xwm tswj tau qhov muag pom kev ncaj ncees los ntawm kev sib sib zog nqus nqus thiab cov txheej txheem spinning-nrog rau qhov roughness tsawg liRa Tsawg dua lossis sib npaug li 0.10 μmrau qib hwm-ua rau cov tuam txhab lag luam kom ua tiav cov kab hluav taws xob tswj tau yooj yim thiab kev ua haujlwm siab tshaj plaws lumen.
Qhov kev ntsuam xyuas dav dav no tshawb txog cov khoom siv hlau metallurgical hauv paus, qhov yuav tsum tau ua ntawm engineering, txheej txheem tsim khoom, daim ntawv thov- cov kev txiav txim siab tshwj xeeb, thiab cov qauv zoo, muab cov lus qhia meej rau cov engineers teeb pom kev zoo, optical designers, thiab procurement specialists.
2. Dab tsi yog 1050 Aluminium Disc
A 1050 aluminium disc yog lub voj voog tiaj tiaj tiaj qhov tseeb - txiav los ntawm cov ntawv txhuas dov lossis coil, tsim los ntawm kev lag luam ntshiab aluminium alloy 1050.
Cov discs no ua cov khoom pib rau kev tsim cov teeb pom kev zoo los ntawm kev sib sib zog nqus nqus, spinning, stamping, lossis hydroforming txheej txheem.
2.1 1050 Alloy Overview
1050 txhuas belongs rau 1000 series ntawm kev lag luam ntshiab txhuas alloys, yam ntxwv los ntawm qhov tsawg kawg nkaus txhuas cov ntsiab lus ntawm99.50%.
Cov tshuaj muaj pes tsawg leeg yog nruj tswj hwm kom txo qis impurities uas tuaj yeem cuam tshuam rau kev ua haujlwm kho qhov muag:
| Element | Cov ntsiab lus (%) | Function/Rationale |
|---|---|---|
| Aluminium (Al) | Ntau dua lossis sib npaug rau 99.50 | Base hlau; siab purity tseem ceeb rau kev xav |
| Silicon (Si) | Tsawg dua los yog sib npaug li 0.25 | Tswj impurity; minimized kom txo lub teeb tawg |
| Hlau (Fe) | Tsawg dua lossis sib npaug li 0.40 | Tswj impurity; cuam tshuam anodizing zoo |
| Copper (Cu) | Tsawg dua los yog sib npaug li 0.05 | Tswj impurity; minimized rau corrosion kuj |
| Manganese (Mn) | Tsawg dua los yog sib npaug li 0.05 | Tswj impurity |
| Magnesium (Mg) | Tsawg dua los yog sib npaug li 0.05 | Tswj impurity |
| Zinc (Zn) | Tsawg dua los yog sib npaug li 0.05 | Tswj impurity |
| Titanium (Ti) | Tsawg dua lossis sib npaug li 0.03 | grain refiner |
Lub siab purity ua kom cov hlau tsis sib xws thaum lub sij hawm tsim thiab muab qhov huv si, tsis xws luag -dawb substrate rau kev ua tiav tom ntej.
2.2 Kev kub ntxhov rau kev siv teeb pom kev zoo
O temper (tag nrho annealed)yog ib qho khoom siv rau cov discs npaj rau kev tsim rau hauv cov reflectors. O temper maximizes ductility thiab minimizes kev pheej hmoo ntawm kev tawg thaum lub sij hawm loj yas hom (sib sib zog nqus nqus, spin forming).
Qee daim ntawv thov yuav siv lub zog me me- tawv tawv (H-series) yog tias yuav tsum muaj lub caij nplooj ntoo hlav ntxiv tom qab tsim, tab sis H tempers txo qhov kawg formability.
2.3 Hom Specification Range
Cov lus qhia tshwj xeeb rau 1050 aluminium discs tuaj yeem sib txawv raws li cov ntawv thov, tab sis muaj ntau yam xws li:
Thickness:Feem ntau los ntawm0.3mm txog 5.0mm, txawm tias cov ntawv thov tshwj xeeb yuav xav tau sab nraud qhov no. Feem ntau cov thicknesses rau cov reflectors feem ntau ntawm 0.5 hli thiab 2.0 hli.
Txoj kab uas hla:Los ntawm50mm txog 1200mm, nrog kev cai ntau thiab tsawg muaj. Qhov loj me yog nyob ntawm qhov tsim ntawm luminaire.
Nto tiav:Pib muab los ua ib lub zeb tiav, npaj rau tom qab polishing, tshuaj brightening, los yog anodizing. Qhov tseem ceeb ntawm no yog ib qho chaw du thiab huv si, tsis muaj qhov tsis xws luag uas tuaj yeem cuam tshuam kev kho qhov muag.
Kev kam rau siab:Kev ua raws li cov qauv thoob ntiaj teb xws li ASTM B209 lossis EN 485-4 rau qhov ntev ntev (thickness, txoj kab uas hla, flatness) yog qhov tseem ceeb rau cov khoom siv hluav taws xob zoo ib yam.
3. Vim li cas 1050 Aluminium Disc rau Teeb pom kev zoo Reflector?
Kev xaiv ntawm 1050 txhuas rau lub teeb pom kev zoo tsis yog coincidental; nws yog kev txiav txim siab xaiv tsav los ntawm kev sib txuam ntawm cov khoom siv zoo tshaj plaws thiab kev tsim khoom zoo.
3.1 Optical Performance Potential
Qhov no yog arguably tus cwj pwm tseem ceeb tshaj plaws . 1050 txhuas lub siab purity ncaj qha mus rau nws lub peev xwm tshwj xeeb kom ua tiav qib siab ntawm specular thiab diffuse reflectivity raws li kev kho kom zoo.
High Specular Reflectance:Tom qab daim iav polishing thiab tshuaj brightening, 1050 txhuas tuaj yeem ua tiav qhov kev xav tau qhov tseem ceeb tshaj85-90%nyob rau hauv qhov pom lub teeb spectrum. Qee qhov kev kho mob tshwj xeeb (piv txwv li, lub tshuab nqus tsev metallization nrog ib txheej nyiaj ntxiv) tuaj yeem thawb qhov no ntau dua, mus txog95-97%. Qhov no txhais tau tias tsawg kawg lub teeb poob thiab tswj lub teeb meej.
Kev sib raug zoo:Cov txheej txheem microstructure uas ua los ntawm nws cov purity ua kom muaj kev cuam tshuam zoo ib yam thoob plaws tag nrho saum npoo ntawm lub reflector, tiv thaiv qhov kub thiab txias tsis sib xws.
3.2 Processability
Qhov zoo tshaj plaws ductility thiab formability ntawm 1050 txhuas hauv O temper ua rau nws hloov tau rau ntau yam txheej txheem.
Kev kos duab sib sib zog nqus:Nws tuaj yeem sib sib zog nqus- kos rau hauv cov duab parabolic lossis elliptical uas muaj kev pheej hmoo tsawg heev ntawm tearing lossis wrinkling.
Khiav:Haum rau spinning txheej txheem los tsim intricate reflector profiles, tso cai rau tsim yooj.
Nias / Stamping:Ua tau zoo rau siab - ntim ntau lawm ntawm cov ntaub ntawv yooj yim dua reflector.
Qhov yooj yim ntawm kev ua no txo cov nqi tsim khoom thiab tso cai rau kev ywj pheej tsim ntau dua hauv kev tsim cov khoom siv kho qhov muag tshwj xeeb.
3.3 Deg Engineering Adaptation: Polishing, Tshuaj Brightening, thiab Anodizing
1050 txhuas qhov saum npoo teb tau zoo heev rau ntau yam kev ua tiav, uas yog qhov tseem ceeb rau nws txoj haujlwm kho qhov muag.
Mechanical Polishing:Muab qhov chaw pib du, tshem tawm micro- khawb thiab npaj rau kev kho tshuaj.
Tshuaj Brightening:Cov kauj ruam tseem ceeb uas cuam tshuam nrog cov tshuaj etching hauv cov kua qaub da dej kom yaj qhov tsis zoo ntawm qhov chaw, ua rau muaj qhov ci ntsa iab, daim iav- zoo li ua tiav. Cov txheej txheem no muaj txiaj ntsig zoo dua rau siab -purity alloys zoo li 1050.
Anodizing:(Electrochemical passivation) Thaum nws tuaj yeem txo qis kev cuam tshuam me ntsis (los ntawm 3-5%), ntshiab anodizing muab cov txheej txheem ruaj khov, pob tshab, thiab tawv oxide uas tiv thaiv lub ntsej muag zoo heev los ntawm khawb, xeb, thiab kev puas tsuaj ib puag ncig, yog li ua kom lub sijhawm ntev kho qhov muag. Qhov no yog qhov tseem ceeb tshwj xeeb rau kev teeb pom kev sab nraum zoov lossis hnyav ib puag ncig.
3.4 Lub teeb yuag thiab Thermal Management
Lub teeb:Nrog ib tug ceev ntawm kwv yees li2.7 g / cm³, aluminium yog ho sib dua li cov ntaub ntawv xws li hlau los yog iav. Qhov no txo qhov hnyav tag nrho ntawm luminaires, simplifying installation, txo cov txheej txheem load, thiab txo nqi tsheb thauj mus los.
Thermal conductivity:Raws li tau hais, 1050 txhuas lub thermal conductivity zoo heev (209 W/m·K) yog qhov tseem ceeb rau cov teeb pom kev zoo niaj hnub, tshwj xeeb tshaj yog nrog siab -faiv fab LEDs. Nws muaj txiaj ntsig zoo tshem tawm cov cua sov tawm ntawm lub teeb ci, pab tswj kev ua haujlwm kom zoo, uas ua rau lub neej ntev ntawm LED chips thiab lwm yam khoom siv hluav taws xob, thiab tiv thaiv kev hloov xim.
3.5 Tus nqi thiab cov saw hlau xa khoom kom tiav
Tus nqi -Kev ua tau zoo:1050 txhuas yog tus nqi pheej yig piv rau lwm cov ntaub ntawv muaj kev cuam tshuam zoo li nyiaj lossis cov khoom sib xyaw tshwj xeeb. Nws muaj ntau yam khoom siv thiab kev ua haujlwm paub tab ua rau nws muaj txiaj ntsig kev lag luam.
Supply Chain:Kev lag luam aluminium thoob ntiaj teb yog qhov muaj zog, nrog rau qhov zoo - tsim cov saw hlau rau 1050 alloy, kom ntseeg tau tias muaj cov khoom sib xws thiab cov nqi sib tw.
4. Kev tsim cov txheej txheem ntawm 1050 Aluminium Discs rau lub teeb pom kev zoo
Kev tsim cov qib siab - zoo 1050 txhuas discs rau lub teeb pom kev zoo yog ib qho txheej txheem ntau -theem yuav tsum tau ua kom zoo thiab tswj xyuas kom nruj.
4.1 Raw Material Preparation
Cov txheej txheem pib nrog siab -purity aluminium ingots. Rau cov ntawv thov kho qhov muag, cov tuam txhab lag luam feem ntau teev cov thawj txhuas uas muaj cov impurity tsawg heev los xyuas kom meej qhov zoo tshaj plaws ua tiav tiav thiab muaj kev cuam tshuam.
Ingots yog melted nyob rau hauv lub cub tawg, thiab tej yam tsim nyog alloying (txawm hais tias tsawg heev rau 1050) los yog fluxing agents yog ntxiv, ua raws li los ntawm degassing kom tshem tawm cov yaj hydrogen thiab pom kom tshem tawm inclusions, kom huv si yaj.
4.2 Rolling txheej txheem
Lub molten aluminium yog cam khwb cia rau hauv loj slabs, uas ces undergo:
Kub Rolling:Slabs yog rhuab mus rau qhov kub thiab txias (xws li, 400-500 degree) thiab dhau los ntawm cov chais kom txo lawv cov thickness ho, refine lub grain qauv, thiab ua tiav ib homogeneous khoom.
Txias Rolling:Tom qab kub dov, cov khoom yog ntxiv txo nyob rau hauv thickness ntawm chav tsev kub. Txias dov muab kev tswj zoo tshaj plaws ntawm qhov ntsuas kawg, txhim kho qhov zoo, thiab ua kom lub zog siv zog (ua haujlwm hardening). Rau cov ntawv thov reflector, lub hom phiaj feem ntau yog ib qho kawg nkaus thickness nrog tsawg kawg nkaus defects.
4.3 Annealing rau O Temper
Tom qab txias dov, aluminium coils raug rau cov txheej txheem annealing.
Tag nrho Annealing:Cov khoom yog rhuab mus rau ib tug tshwj xeeb kub (xws li, 340-410 degree) rau lub sij hawm tswj thiab maj mam txias. Cov txheej txheem no recrystallizes cov qauv nplej, txo cov kev ntxhov siab sab hauv vim tias thaum lub caij txias dov, thiab rov ua cov khoom siv rau nws cov mos mos, ductile "O" temper. Qhov no yog qhov tseem ceeb heev rau kev ua haujlwm tom ntej rau hauv cov duab reflector.
4.4 Kev Npaj Nto rau Optical Finishing
Thaum lub aluminium coil los yog daim ntawv tawm ntawm lub zeb nrog ib tug du nto, kev npaj ntxiv yog feem ntau yuav tsum tau ua ntej kho qhov muag. Qhov no suav nrog:
Ntxuav:Tshem tawm cov roj dov, plua plav, thiab lwm yam kab mob uas siv cov tshuaj aqueous degreasing.
Txhuam / Buffing (yeem):Kev kho tshuab kom tshem tawm tej yam me me ntawm qhov tsis zoo los yog ua ntej - polishing nto kom zoo dua cov tshuaj lom neeg ntxiv.
4.5 Txheej Txheej Txheej Txheej
Cov no feem ntau ua tom qab lub disc tau tsim rau hauv nws qhov kawg reflector zoo, tab sis cov khoom siv hauv paus yuav tsum tau npaj rau nws.
Daim iav Polishing:Cov tshuab polishing siv cov tshuaj abrasive kom ua tau zoo heev, ze rau - daim iav tiav. Qhov no tshem tawm macro- nplai khawb thiab txhim kho qhov gloss zoo.
Tshuaj Brightening:immersion nyob rau hauv cov tshuaj tshwj xeeb da dej (xws li, phosphoric-nitric acid sib tov) uas xaiv dissolves lub txhuas nto, tsim ib tug microscopic smoothing nyhuv thiab txhim kho qhov specular reflectance. Cov kauj ruam no yog rhiab heev rau alloy purity.
Anodizing:Cov txheej txheem electrochemical uas cov txhuas tau muab tso rau hauv cov tshuaj electrolytic (xws li sulfuric acid) thiab hluav taws xob tam sim no dhau. Qhov no tsim cov pob tshab, tawv, thiab corrosion-resistant aluminium oxide txheej rau ntawm qhov chaw, sealing lub reflective tiav. Rau optical reflectors, ntshiab anodizing yog siv los khaws cov pob tshab thiab muaj kev cuam tshuam siab.
4.6 Disc Blaking
Qhov no yog cov txheej txheem ntawm kev txiav cov tiav 1050 txhuas ntawv lossis coil rau hauv cov voj voog zoo.
Punching / Stamping:Rau cov ntim ntau dua thiab cov qauv loj, hydraulic presses nrog cov tuag yog siv los xuas nrig ntaus tawm discs zoo.
Shearing / Laser Txiav:Rau qhov loj lossis kev cai- cov discs loj, cov tshuab shearing siab heev lossis cov tshuab laser txiav tshuab tau ua haujlwm los xyuas kom meej cov npoo huv si thiab cov khoom me me deformation. Kev saib xyuas ntug zoo yog qhov tseem ceeb los tiv thaiv qhov tsis xws luag uas tuaj yeem nthuav tawm thaum lub sijhawm tsim tom ntej.
5. Daim ntawv thov ntawm 1050 Aluminium Discs rau lub teeb pom kev zoo
5.1 Kev lag luam thiab kev lag luam teeb pom kev zoo
High Bay thiab Low Bay Luminaires:Qhov tseem ceeb rau kev coj teeb pom kev zoo hauv cov tsev khaws khoom, cov chaw tsim khoom, thiab cov chaw muag khoom loj, feem ntau ua ke nrog LED lossis HID qhov chaw. Lub siab reflectance ua kom lub teeb ci siab tshaj plaws rau lub dav hlau ua haujlwm.
Chaw Ua Haujlwm & Khw Muag Khoom Teeb Pom Kev:Siv nyob rau hauv downlights, taug qab teeb pom kev zoo, thiab vaj huam sib luag teeb kom muab cov teeb pom kev zoo sib xws thiab txo qis glare. Piv txwv li, ib tug raug 150mm txoj kab uas hla 1050 txhuas disc rau teeb pom kev zoo reflector nyob rau hauv lub downlight yuav ua tau ib tug beam kaum sab xis ntawm 60-90 degrees nrog ntau tshaj 88% optical efficiency.
5.2 Teeb pom kev zoo nyob
Teeb pom kev zoo (Downlights):Feem ntau nyob rau hauv cov tsev rau ambient thiab ua hauj lwm teeb pom kev zoo, qhov twg compact thiab npaum lub teeb yuav tsum tau.
Decorative Fixtures:Muaj peev xwm ua tau zoo li hauv ntau hom los tsim lub teeb pom kev zoo nkauj tshwj xeeb thaum tswj xyuas lub teeb pom kev zoo.
5.3 Sab nraum zoov & Public teeb pom kev zoo
Txoj Kev Teeb & Thaj Chaw Teeb:Qhov tseem ceeb rau kev coj lub teeb mus rau txoj kev thiab txoj hauv kev, ua kom muaj kev nyab xeeb thiab pom kev. Anodized 1050 reflectors muab cov huab cua tsim nyog.
Floodlights & Security Lighting:Siv nyob rau hauv chaw ntau pob, chaw nres tsheb, thiab lub tsev facades, qhov twg muaj zog, taw qhia lub teeb yuav tsum tau.
5.4 Automotive Teeb pom kev zoo
Headlights (Low thiab High Beam):Precisely engineered 1050 reflectors yog qhov tseem ceeb rau kev tsim cov kab teeb tshwj xeeb uas ua tau raws li cov kev cai nruj nruj thiab ua kom pom tseeb ntawm tus neeg tsav tsheb. Piv txwv li, parabolic reflector tuaj yeem ua kom pom dav dav, txawm tias kis tau los ntawm lub teeb, thaum lub ellipsoidal reflector tuaj yeem sib sau lub teeb ntau dua rau lub teeb tsom.
Fog Lights & Signal Lights:Pab txhawb rau tag nrho lub tsheb kev nyab xeeb los ntawm kev ua kom lub teeb pom kev zoo nyob rau hauv cov xwm txheej nyuaj.
5.5 Tshwj xeeb teeb pom kev zoo
Theem & Studio Teeb pom kev zoo:Siv nyob rau hauv qhov chaw ua yeeb yam thiab tshaj tawm xov xwm rau tsom teeb tsom teeb thiab teeb pom kev zoo, qhov chaw tswj lub teeb yog qhov tseem ceeb.
Kev Kho Mob & Kho Hniav Teeb:Muab lub teeb ci, zoo ib yam, thiab duab ntxoov ntxoo-dawb illumination rau kev kuaj thiab phais cov txheej txheem.
Horticultural Teeb pom kev zoo (Grow Lights):Maximize PPFD (Photosynthetic Photon Flux Density) qhia rau cov nroj tsuag, optimizing kev loj hlob.
5.6 LED Architectural & Decorative Teeb pom kev zoo
Nrog kev nce siab ntawm LED thev naus laus zis, 1050 txhuas disc rau lub teeb pom kev zoo yog tsim los nrog ntau dua micro-facets thiab textures kom tswj cov teeb pom kev zoo los ntawm cov teeb pom kev zoo LED, tsim cov teeb pom kev zoo thiab ua tiav cov teeb pom kev zoo rau cov qauv tsim vaj tsev niaj hnub.
6. Kev sib piv nrog lwm cov khoom siv thiab cov alloys
| Khoom / Khoom | Tom ntej: AA-1050 (O) | AW-3003/3004 | AA-5052/5xxx | Stainless hlau (304/430) | Khoom siv (Al + SS) | PVD Metallized Yas |
|---|---|---|---|---|---|---|
| Thermal conductivity (W / m · K) | 200–230 | 150–170 | 110–140 | 14–16 | Nyob ntawm (Al core dominant) | ~ 0.2 (tsawg kawg) |
| Qhov ceev (g / cm³) | 2.71 | 2.73 | 2.68 | ~7.9 | Composite | 1.0–1.3 |
| Tensile zog (MPa) | 40–90 (O) | 100–170 | 200–300 | 200–520 | Ntau yam | Tsawg |
| Specular Reflectance (%) | 86–92 | 84–90 | 80–88 | 60–75 | 80–90 | 60–85 |
| Formability | Zoo heev | Zoo heev | Zoo | Poor – Nruab nrab | Zoo | Zoo heev |
| Nyhav Advantage | Zoo heev | Zoo heev | Zoo heev | pluag | Nruab nrab | Zoo heev |
| Corrosion Resistance | Zoo | Zoo | Zoo heev | Zoo heev | Zoo heev | Nruab nrab |
| Thermal Management | Zoo heev | Zoo heev | Zoo | pluag | Zoo heev | pluag |
| Surface Finish Potential | Zoo heev (daim iav polish) | Zoo heev | Zoo | Zoo | Zoo | Zoo (thawj) |
| Durability | Nruab nrab | Zoo | Zoo heev | Zoo heev | Zoo heev | Nruab Nrab - Tsawg |
| Tus nqi txheeb ze | Tsawg | Tsawg-Medium | Nruab nrab | Siab | Siab | Tsawg-Medium |
| Tej kev siv | Nyob sab hauv tsev reflectors, downlights | Muaj zog reflectors | Sab nraum zoov / loj fixtures | Ib puag ncig hnyav | Hwm / induction | Kho kom zoo nkauj, tsawg- teeb pom kev zoo |
7. Cov qauv zoo thiab cov ntawv pov thawj
Kev ua raws li cov qauv kev ua tau zoo yog qhov tseem ceeb rau 1050 aluminium disc rau lub teeb pom kev zoo, ua kom muaj kev ua tau zoo thiab kev ntseeg tau.
Khoom siv:Conformance thoob ntiaj teb cov qauv zoo liASTM B209 (Txheej txheem Specification rau Aluminium thiab Aluminium -Alloy Sheet thiab Phaj)los yogTS EN 573-3 (Aluminium thiab aluminium alloys - Cov tshuaj muaj pes tsawg leeg thiab daim ntawv ntawm cov khoom)rau 1050 alloy.
Dimensional Tolerances:Specifications tswj los ntawm cov qauv xws liTS EN 485-A-4 (Aluminium thiab aluminium alloys - Daim ntawv, sawb thiab phaj - Ntu 4: Kev kam rau siab ntawm daim ntawv thiab qhov ntev rau cov khoom txias-dov)los yog cov qauv ASTM cuam tshuam los xyuas kom meej qhov sib xws ntawm cov kab uas hla, tuab, thiab flatness.
Nto Zoo:Kev soj ntsuam pom cov qauv rau qhov tsis xws luag (scratches, inclusions, pits) thiab kev ntsuas kom muaj nuj nqis rau qhov roughness (piv txwv li, Ra qhov tseem ceeb) ua ntej thiab tom qab ua tiav.
Optical Performance:
Spectrophotometric Analysis:Ntsuas spectral reflectance thoob plaws qhov pom spectrum (thiab qee zaum UV / IR) kom paub meej tias xav tau kev xav.
Kev kuaj Goniphotometric:Siv los qhia txog tag nrho lub teeb faib nkhaus ntawm lub teeb pom kev tiav, kom ntseeg tau tias nws ua tau raws li cov lus qhia ntawm lub teeb thiab siv.
Corrosion Resistance:Cov tshuaj tsuag ntsev (xws li, ASTM B117) lossis lwm yam kev ntsuas huab cua nrawm rau anodized reflectors kom paub meej ntev -lub sij hawm durability.
ISO 9001 Daim Ntawv Pov Thawj:Ua kom pom lub chaw tsim khoom cog lus rau kev tswj hwm kev ua haujlwm zoo thoob plaws hauv cov txheej txheem tsim khoom.
RoHS / REACH Ua Raws:Ua kom cov khoom siv thiab cov txheej txheem tsim khoom ua tau raws li cov cai tswj hwm ib puag ncig thiab muaj kev phom sij.
8. Vim li cas thiaj xaiv Huawei 1050 Aluminium Discs rau Teeb pom kev zoo Reflectors
Yog tias koj tab tom ntsuas tus neeg muag khoom muaj npe xws liHuawei, nrhiav:
Traceable zeb xeem daim ntawv pov thawjrau alloy thiab temper (ua kom rov ua dua thiab kho qhov muag tau).
Pom pom muaj peev xwm kho qhov muag- piv txwv reflectance spectra thiab goniophotometer cov ntaub ntawv los ntawm cov haujlwm ua ntej.
Kev tsim nyog txheej txheej: thermal endurance ntawm LED hlws ris kub, tsis tshua muaj yellowing, adhesion thiab abrasion kev ua tau zoo.
Cov txheej txheem tswj kev tsim: tsim strain mapping, tuag tu cov ntaub ntawv thiab seem/yield statistics.
Kev tswj kom zoo: ISO certification, inspection incoming, lot traceability and corrective -cov txheej txheem ua.
Supply chain peevkom ua tau raws li qhov ntim ntau lawm nrog zoo ib yam thiab batch uniformity.
9. Cov lus xaus
Lub 1050 txhuas disc rau teeb pom kev zoo reflector, txhawb nqa kev ua tau zoo thiab kev ua haujlwm ntawm ntau lub luminaires thoob ntiaj teb.
Nws lub siab purity pub rau nws qhov tshwj xeeb kho qhov muag muaj peev xwm, ua rau nws haum rau cov kev kho mob saum npoo av uas ua rau muaj kev xav zoo siab.
Ua ke nrog nws cov txheej txheem ua tau zoo, muaj peev xwm tswj tau zoo thermal, lub teeb yuag, thiab tus nqi -kev ua tau zoo, 1050 txhuas muaj cov kev daws teeb meem rau ntau hom kev siv teeb pom kev zoo.
Raws li lub teeb pom kev siv thev naus laus zis txuas ntxiv mus, tshwj xeeb tshaj yog nrog kev loj hlob ntawm LEDs, qhov kev thov rau siab -kev ua tau zoo, ruaj khov, thiab cov khoom siv hluav taws xob ua kom pom tseeb tsuas yog ua kom hnyav dua.
Lub 1050 aluminium disc, txhawb nqa los ntawm cov qauv nruj nruj thiab kev tsim kho tshiab txuas ntxiv, tau npaj los txuas ntxiv nws lub luag haujlwm tseem ceeb hauv kev tsim lub neej yav tom ntej ntawm kev teeb pom kev zoo.
FAQs
Q1: Dab tsi yog qhov zoo tshaj plaws ntawm 1050 txhuas dua lwm cov aluminium alloys rau reflectors?
A1: Lub ntsiab kom zoo dua yog nws cov purity siab (yam tsawg kawg nkaus 99.5% txhuas), uas tso cai rau nws ua tau zoo dua specular reflectance tom qab tshuaj brightening thiab anodizing piv rau alloys xws li 3003 los yog 5052, uas muaj ntau alloying ntsiab uas cuam tshuam nrog optical finishing.
Q2: Vim li cas qhov "O" temper tseem ceeb rau 1050 txhuas discs hauv daim ntawv thov reflector?
A2: "O" temper (tag nrho annealed) qhia qhov siab tshaj plaws ductility thiab formability. Lub xeev mos no yog qhov tseem ceeb rau kev tso cai rau cov disc kom sib sib zog nqus- kos, spun, los yog nias rau hauv cov duab parabolic lossis elliptical reflector yam tsis muaj tawg lossis tawg, uas yuav nyuaj nrog kev kub ntxhov.
Q3: Ua li cas 1050 txhuas ua rau lub neej ntev ntawm LED teeb pom kev zoo?
A3: 1050 txhuas muaj thermal conductivity zoo heev (kwv yees . 209 W/m·K). Qhov no tso cai rau nws kom ua tau zoo dissipate cua sov tsim los ntawm LED modules, ua kom lawv nyob rau hauv qhov zoo tshaj plaws kev khiav hauj lwm kub. Kev ua haujlwm qis qis ua rau lub neej ntev ntawm LED chips thiab cov khoom siv hluav taws xob cuam tshuam, tiv thaiv kev puas tsuaj ntxov ntxov thiab hloov xim.
Q4: Cov kev kho deg dab tsi yog feem ntau siv rau 1050 aluminium reflectors los txhim kho kev cuam tshuam thiab ua haujlwm ntev?
A4: Cov kev kho mob feem ntau suav nrog kev kho tshuab polishing, tshuaj lom neeg ci ci (kom ua tiav daim iav- zoo li tiav), thiab ntshiab anodizing. Anodizing tsim ib qho nyuaj, pob tshab oxide txheej uas tiv thaiv qhov chaw cuam tshuam los ntawm khawb, corrosion, thiab ib puag ncig yam, kom ntseeg tau ntev - lub sijhawm kho qhov muag.
Q5: Puas yog 1050 txhuas discs tuaj yeem siv dua?
A5: Yog lawm, txhuas yog cov khoom siv rov ua dua tshiab . 1050 txhuas yog 100% recyclable yam tsis muaj qhov tseem ceeb ntawm nws cov khoom, ua rau nws xaiv ib puag ncig zoo. Qhov no pab txhawb rau kev lag luam ncig thiab txo lub zog xav tau rau thawj cov khoom siv txhuas.
